"Frequency : [TX/RX] 136. MHz [RX Only] 76-108 MHz Mode : F3E (16K0F3E/11K0F3E / RX Only WFM) Progammable Channels : 128 Channels Frequency Stability : 2.5ppm Power Supply Requirement : 7.4V DC Dimensions : 59W x 98H x 35D mm Transmitter : Output Power : Approx. 5/2/0.5W Modulation System : Variable Reactance FM Spurious Emissions : Less Than -36 dB Max Frequency Deviation : 5kHz / 2.5kHz Receiver : receive System : Double Conversion Superheterodyne Inter Mediate Frequencies : 38.85MHz Sensitivity (12dB SINAD wide/Narrow) Selectivity : -6dB: -6dB: Wide12kHz / Narrow 10kHz Audio Output Power : 1000mW (8Ohm / Max)" Read more
"Frequency : [TX/RX] 136. MHz
[RX Only] 76-108 MHz
Mode : F3E (16K0F3E/11K0F3E / RX Only WFM)
Progammable Channels : 128 Channels
Frequency Stability : 2.5ppm
Power Supply Requirement : 7.4V DC
Dimensions : 59W x 98H x 35D mm
Transmitter :
Output Power : Approx. 5/2/0.5W
Modulation System : Variable Reactance FM
Spurious Emissions : Less Than -36 dB
Max Frequency Deviation : 5kHz / 2.5kHz
Receiver :
receive System : Double Conversion Superheterodyne
Inter Mediate Frequencies : 38.85MHz
Sensitivity (12dB SINAD wide/Narrow)
Selectivity : -6dB: -6dB: Wide12kHz / Narrow 10kHz
Audio Output Power : 1000mW (8Ohm / Max)"
| Specifications | Descriptions |
|---|---|
| No Specifications | |
